Wireless controller for RGB LED strips with 24-button remote control, 12V, 6A, 72W
The controller with a remote is the essential component of all accessories for RGB LED strips. It allows wireless control of the lighting based on preferences. The controller is equipped with 16 pre-programmed colors that can be activated using a dedicated button on the remote. It has four basic color-changing functions – steady light, flashing light, as well as smooth transitions and jump transitions. The remote also has additional buttons that allow you to adjust the brightness of the colors. Communication between the controller and the remote takes place via infrared (IR). This means that one remote can control identical receivers. However, it requires pointing the remote towards a specific controller. The controller, with an IP20 protection rating, is designed for indoor use. The maximum LED strip power at 12V must not exceed 72W.
Product Type: Mini Controller
Application: RGB LED Strips
Control Method: Remote
Control (number of buttons): 24
Communication Range [m]: 5-8
Remote Power Supply: 3V CR2025
Control Type: IR
Transmission Frequency: 38 kHz
Output Voltage Range [V]: 5-24
Input Voltage Range [V]: 5-24
Current/Channel [A]: 2
Maximum Output Current [A]: 6
Max. LED Strip Power: 12V 72W
Max. Load Power for All Channels: 12V 72W
Protection Rating (IP): IP20
Color: RGB
Receiver Input/Output Voltage: 5-24V
Receiver Output Count: 1
Color Channel Count: 3
Programmable: No
